首頁 > 產品中心 > 噴砂機系列噴砂機系列
◆技術參數 Main technical parameters （請往下瀏覽有大量案例照片供參考）
|
機器型號 Model |
STR-9070/9080 |
STR-1010 |
|
工作艙尺寸 Internal size(mm) |
900×800×650 |
1000×1000×790 |
|
整機尺寸 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
|
電源 Power |
220V 50Hz |
220V 50Hz |
|
機器照明燈 Machine floodlight |
一盞60W防爆燈 |
220V 13W節能燈 |
|
滾筒承重 Roller bearing |
10-30Kg |
10-30Kg |
|
分離器電機 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
|
分離器風量 Separator air volume |
8.5m3/min |
8.5m3/min |
|
壓縮空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
機器重量 Weight |
320kg |
380 kg |
◆產品特點 Product features
1. 設計新穎、美觀大方、結構科學、操作方便;
2. 自動控制自動噴砂，具備定時噴砂，點動定位等功能;
3. 滾筒外徑及噴槍數量可根據客戶需求設計制作;
4. 即可手動，又可自動，噴砂品質好，一機多用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆適用范圍 Applicable scope
適用于大量小工件的手動或自動噴砂，例如：電木制品、螺絲、塑膠制
品、鈕扣、拉鏈、壓克力、機器零部件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
